Drive Axle Forklift

Drive Axle Forklift - A lift truck drive axle is actually a piece of machinery which is elastically affixed to a vehicle frame using a lift mast. The lift mast is attached to the drive axle and is capable of being inclined round the drive axle's axial centerline. This is done by at the very least one tilting cylinder. Forward bearing parts along with rear bearing components of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle can be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing elements. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is affixed to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Model H40, H45 and H35 forklifts, which are produced by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle frame itself. The drive axle is elastically attached to the frame of the forklift using numerous different bearings. The drive axle has tubular axle body along with extension arms affixed to it and extend backwards. This particular kind of drive axle is elastically attached to the vehicle frame by back bearing elements on the extension arms together with frontward bearing tools situated on the axle body. There are two back and two front bearing tools. Each one is separated in the transverse direction of the vehicle from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle on tis particular model of forklift are sustained by the extension arms through the rear bearing parts on the frame. The forces produced by the load being carried and the lift mast are transmitted into the floor or street by the vehicle frame through the front bearing components of the drive axle. It is important to ensure the elements of the drive axle are configured in a rigid enough method to maintain immovability of the lift truck truck. The bearing elements can lessen minor bumps or road surface irregularities through travel to a limited extent and offer a bit smoother function.
